CAT MFL

Lube Bodies

Genuine Mega Design for Lube Bodies (MLT)

Mega's complete line of lube bodies for rigid and articulated trucks are designed for stable operation, proper weight distribution and long life. Mega service bodies feature an integrated power system which uses fuel supplied directly from the platform fuel tank. The body is fully functional with the truck turned off, saving service meter hours, emissions and fuel consumption. The power system allows complete testing in the factory prior to field installation, minimizing labor cost and chassis integration issues. Every service body includes a complete set of technical manuals detailing installation, operation, maintenance, inspection and replacement parts. Mega bodies are constructed with premium materials and are inspected throughout the manufacturing process to ensure reliability.

Mega lube bodies can be purchased for integration with a dealer-provided truck or as a complete solution with a Mega-provided truck. Purchasing your complete solution directly from Mega streamlines the ordering process and significantly reduces the complexities related to delivery timing and shipping.

The general specifications below reflect nominal capacities for Mega standard configurations. Please contact our Mega Sales Team regarding shipping information and models not listed.

  Product
Tank 1
Product
Tank 2
Product
Tank 3
Product
Tank 4
Product
Tank 5
Product
Tank 6
Used Oil Coolant Grease (lb/kg)
Gallons 500 500 500 500 500 250 500 500 1,100 (lb)
Liters 1,890 1,890 1,890 1,890 1,890 945 1,890 1,890 500 (kg)
  Product
Tank 1
Product
Tank 2
Product
Tank 3
Product
Tank 4
Product
Tank 5
Product
Tank 6
Product
Tank 7
Product
Tank 8
Used Oil Coolant Grease (lb/kg)
Gallons 500 500 500 500 500 500 250 250 500 500 1,100 (lb)
Liters 1,890 1,890 1,890 1,890 1,890 1,890 945 945 1,890 1,890 500 (kg)

MLT bodies include the following sta ndard features. Feature specifications may vary by model. For additional information, contact our Mega Sales Team.

The Mega standard air compressor system provides an air tank with water vapor drain, dessicant filter, air dryer and regulator. It also includes a spring-rewind hose reel with threaded hose whip for customer supplied air chucks.

A cable to relocate your camera from the truck to the water tank.

Mega tanks pin directly to the rear pivot mounts of the truck. Line boring the rear pivot mounts ensures accurate direct pin installation of the tank. Mega tanks do not require welding to the frame. New pivot pins and shims are supplied with the tank.

The mobile control valve has a single CAN bus connection and precision software control which reduces wiring and hydraulic connection complexity. The system includes pressure, flow rate, soft start/stop troubleshooting feedback.

Mega tanks are abrasive blasted prior to application of anti-corrosive primer. The exterior top coat is color matched to the current manufacturers color.

The truck chassis is allowed to flex beneath the spring type front mounting tie downs. No welding is required to install these mounts.

Mega's grease tank includes:

  • Carbon steel tank
  • Remote bottom fill or top fill with overflow safety vent
  • Works with HPLV and LPHV delivery systems

Mega provides a ground-accessible storage cabinet for used oil filters.

The compact switch pad is located in the cab and includes the following features:

  • Simple, rugged construction for heavy duty operation
  • Adjustable switch pad brightness
  • Work light controls
  • Durable switch pad inserts
  • Tank level indicators
  • LED lights in RGB colors
  • CAN bus protocol
  • IP68 ingress waterproof protection

Mega tanks include LED lights for long life and low maintenance:

  • Backup rear stop, turn, tail lights
  • Side marker lights
  • Amber beacon light centered on top of rear cabinet
  • Exterior 24VDC work lights
  • Compartment lighting
  • Operator lighting controls

Mud flaps fore and aft of rear drive tires are standard equipment on all Mega MLT tanks.

Mega's new coolant system includes:

  • Stainless steel tank with interior baffles
  • Exterior visual sight gauge
  • Ground-level fill at operator station
  • Tank overflow bypass plumbing
  • Direct-coupled hydraulically-driven product pump with high pressure filter
  • Spring-rewind hose reel

The new oil tank product systems include:

  • Carbon steel tanks with interior baffles
  • Exterior visual sight gauge
  • Ground-level fill at operators station
  • Tank overflow bypass plumbing
  • Direct-coupled, hydraulically-driven product pump with high pressure filter
  • Spring-rewind hose reel

Mega protects your investment by providing a one-year warranty against defects in materials and workmanship. Extended warranties are available for purchase. Visit our Warranty Page for more information.

Mega's MLT platform structure includes:

  • Raised illuminated walkway between product tanks and lower deck assembly
  • Modular deck and reel cabinet design
  • Upper and lower floor designed to contain product spillage
  • Subfloor painted with industrial grade surface coating to contain product spillage


The operator station, located at the left rear side of the reel cabinet, includes high and low volume diesel fuel dispensing nozzles, product dispensing nozzles and associated controls. Controls are provided for hose operation, fuel and product pumps, fuel register, integrated power system and LED compartment lighting. The dispensing station is segregated from the inner reel cabinet by a fairlead panel to reduce contamination. The lockable hinge door with door stays provides security and easy access. Benefits and features include:

  • LED compartment lighting
  • Enpak® remote control
  • Fuel register
  • Nozzle storage holders
  • Emergency "E-stop" shut-off switch
  • Provides ground level access for operator at left rear of unit
  • Hinged door access with mechanical stays and heavy duty latches
  • Dispensing nozzles separated from service cabinet by bulkhead with roller fairlead panel to reduce dust
  • Engraved metal nameplates labeling each product tank and corresponding controls

MLT rear cabinetThe rear cabinet enclosure provides ground-level access via a lockable hinged door with door stays to:

  • Fuel dispensing filter
  • Fuel pump inlet strainer
  • Product tank fill access
  • Product tank servicing lines
  • Tank-level indicator system for fuel and product tanks
  • Hydraulically-Driven Blackmer Fuel Pump
  • Low volume diesel spring-rewind hose reel
  • High volume hydraulic hose reel
  • Backup camera relocation cabinet

Mega service bodies include an access ladder to the deck. Our standard ladder features tread grip rungs for a sure-footed grip and hand rails at the top of the ladder allowing access to the deck.

Our stainless steel, safety latch-style tank cover meets DOT 178.345.5 specifications. Breather filters are designed to prevent moisture and contaminants from entering the fuel tank.

Mega's reliable technician service screen provides the ability to service your machine with touch screen and video inputs. Features include:

  • Optically-bonded display assembly helps prevent condensation buildup
  • IP68 ingress protection performs at extreme temperatures
  • Routine functions can be completed easily and precisely

Mega provides a complete set of technical manuals detailing installation, operation, maintenance, inspection and replacement parts. Additional manuals are available for purchase. Visit our Technical Manuals Page for more information.

The used oil system includes:

  • Carbon steel tanks with interior baffles
  • Exterior visual sight gauge
  • Pneumatically-operated diaphragm pump for onload and dispensing operations
  • Tank overflow bypass plumbing
  • Spring-rewind hose reel

Your standard MLT body can be configured with these optional features. Availability and specifications may vary by model. For additional information, contact our Mega Sales Team.

Mega offers an additional grease tank and delivery system.

The additional lighting package provides two additional LED lights on the non-operational side of the tank.

Additional sets of manuals are available for purchase. Mega manuals include a complete set of technical manuals detailing installation, operation, maintenance, inspection and replacement parts. Visit our Technical Manuals Page for more information.

Mega offers complete factory installation for all articulated and smaller rigid frame truck models for both customer-supplied and Mega-supplied chassis. Factory installation includes complete commissioning prior to delivery.

The Mega grease delivery system includes a hydraulically-driven pump and spring-rewind hose reel. Mega offers a high pressure low volume system for zerks and a low pressure high volume system for bulk grease delivery.

Mega offers electro-hydraulic upgrades to the standard, spring-rewind hose reels with hose diameters one inch or larger.

The Mega Product Support team offers on-site technical assistance, service advice and training to facilitate implementation and help reduce field assembly and component repair time.

The pressure washer system includes:

  • Stainless steel tank with interior baffling
  • Hydraulically-driven pump
  • Adjustable pressure regulator
  • Suction strainer and filter on pump
  • Hydraulic controls
  • Spring-rewind hose reel with high pressure hose, pistol grip control wand and nozzle

Product dispensing guns include anti-drip hose whips. The electronic or mechanical dial meter with resetting totalizer helps dispense precise amounts of products and aids in tracking material usage.

Mega offers insulated and uninsulated tank enclosures, as well as a heating system for product tanks.

Enclosure features include:
  • Removable top panel with lifting points for easy access to product tanks
  • White interior walls and ceiling
  • Interior light controls
Heating system features include:
  • Heated reel cabinet
  • Flow controls to adjust zone heat
  • Heat loops circulate a heated glycol solution to product tanks to maintain oil viscosity
  • Self-contained diesel-fired closed circuit glycol heater system
  • Dedicated fuel supply from main diesel fuel tank
